Condition: Brand New
range
Reception frequency: <Operating range>
30kHz-74.800MHz
<Warranty range>
500kHz to 29.9999MHz
50.000MHz-54.000MHz
Transmission frequency: 1.810MHz ~ 1.825MHz
1.9075MHz ~ 1.9125MHz
3.500MHz ~ 3.575MHz
3.599MHz ~ 3.612MHz
3.680MHz-3.87MHz
3.702MHz-3.716MHz
3.745MHz-3.770MHz
3.791MHz-3.805MHz
7.000MHz-7.200MHz
10.100MHz-10.150MHz
14.000MHz-14.350MHz
18.068MHz-18.168MHz
21.000MHz-21.450MHz
24.890MHz-24.990MHz
28.000MHz-29.700MHz
50.000MHz-54.000MHz
4630kHz
Mode SSB, CW, RTTY, AM, FM
Number of memory channels 101ch (split 99ch + scan edge 2ch)
Antenna impedance 50Ω (unbalanced)
Antenna terminal M type 1 system
Power supply voltage DC13.8V ± 15%
Current consumption received / 0.9A
Maximum reception output / 1.25A
At the time of transmission (at 100W) /21.0A
Transmission output SSB / CW / RTTY / FM: 100W ~ 2W
AM: 25W ~ 1W
Modulation method SSB: Numerical balanced modulation
AM: Numerical operation type low power modulation
FM: Numerical reactance modulation
Spurious emission intensity <Spurious area>
1.8-28MHz: -50dB or less
50MHz band: -63dB or less
<Out-of-band area>
1.8-28MHz: -40dB or less
50MHz band: -60dB or less
Microphone impedance 600Ω
Reception method Direct sampling superheterodyne method
Intermediate frequency 36kHz
Reception sensitivity
(TY P)
SSB / CW / RTTY
(At 10dB S / N) 1.8-29.9MHz: -16dBμ (0.15μV) (when preamplifier 1 is ON)
50MHz band: -18dBμ (0.12μV) (when preamplifier 2 is ON)
AM (at 10dB S / N) 0.5-1.8MHz: + 22dBμ (13.0μV) (when preamplifier 1 is ON)
1.8-29.995MHz: + 6dBμ (2.0μV) (when preamplifier 1 is ON)
50MHz band: 0dBμ (1.0μV) (when preamplifier 2 is ON)
FM
(At 12dB SINAD) 28.0MHz to 29.7MHz: -6dBμ (0.50μV) (when preamplifier 1 is ON)
50MHz band: -12dBμ (0.25μV) (when preamplifier 2 is ON)
Squelch sensitivity
(Threshold) SSB + 15dBμ (5.6μV) or less
FM -10dBμ (0.3μV) or less
(HF band / preamplifier 1 ON, 50MHz band / preamplifier 2 ON)
Spurious interference ratio 70 dB or more
Low frequency output 2.5W or more (8Ω load, 1kHz, 10% distortion factor)
Low frequency load impedance 8Ω
